How to Design & Layout Your Control System

Some ideas and tips to help you in your next control panel design.

Introduction

Does your control panel look this organized? Are your technicians and field personnel intimidated by the components and wiring in your control cabinet? If you are not entirely happy with the wiring and the layout in your control cabinet then you should consider some of the products and services available from Automation Systems Interconnect. In addition to helping you design and lay out a superior control system you will find high quality products, immediately available at excellent prices when you visit ASI at www.asi-ez.com.

In the meantime, here are some ideas/tips that may help you in your next panel design:

  • Step n°1 |

    Ground blocks.

    When you lay out your din rails with IEC terminal blocks consider putting the ground blocks at each end of the assembly, thereby eliminating the need for end clamps.
    How to Design & Layout Your Control System image
  • Step n°2 |

    Match the terminal block to the size of the wire.

    Make sure to match the terminal block to the size of the wire in the panel. It is amazing how many people waste money by over-sizing the terminal blocks.
    How to Design & Layout Your Control System image
  • Step n°3 |

    Consider multiple level terminal blocks.

    If space is a problem then consider multiple level terminal blocks, especially those with added functions such as disconnects, fusing, ground and sensor connections.
    How to Design & Layout Your Control System image
